PRODUCT DETAILS

With digital readout

Max workpiece size: 300mm(W) x 250mm(H)

Distance from blade to conveyor table

8-125mm (For 4-125mm will be upon request)

Conveyor belt size

285mm x 5470mm

Saw wheel dimension

Φ28" x 2"(Thickness)

Max feed speed

45 M/min.

Saw blade size

168" x 2"

Saw wheel motor

30HP With Inverter 30HP

Controlling blade tension

Pneumatic-Hydraulic system

Conveyor Motor

2HP With Inverter 2HP

Saw-head Up & Down  Motor

1/4HP

Dust hood diameter

ψ4" x4

Net weight

950kgs

Packing dimensions with pallet

- Frame   : 2170 x 1100 x 1120mm / 901kgs
- Conveyor: 2870 x 620 x 750mm / 207kgs

Min. working length request

500mm (For shorter will be upon request)

Pneumatic pressure roller system

For accurate cutting

Front & Back Bumper

Front pressure roller with air cylinder and shock absorber

Tolorance

(5-25 M/min. ±0.1ｍｍ) (25-45 M/min. ±0.3mm)

Mist coolant system

With saw dust Scraper and Wool Pad

Saw kerf

1.35mm

_______Volt, _______Hertz

With pressure roller height adjustment system
