Product Details

Max. / Min. Width

300mm / 40mm

Max. / Min. Thickness

10mm / 35mm

Min. Board Length

270mm

Max. Board Length

Unlimited

Max. Board Weight

15kgs

Cutterhead Motors

5-1/2HP x2 (Optional: 7-1/2HP x2 or 10HP x2)

Feeding Pressure Roller Motor

5-1/2HP x2 (Optional: 7-1/2HP x2 or 10HP x2)

Feeding Pressure Roller Motor

1HP W/1HP Inverter

Infeed Conveyor Table Motor

1/2HP (Optional: Variable Feed 1HP Inverter)

Cutterhead Feeding Motor (Forward & Backward)

Backward): 1/2HP W/1HP Inverter

Cutterhead Spindle Diameter

Φ40mm

Max. cutter head dia.

160mm

Cutterhead Type

TCT Disposable Inserts

(L): 14*14*2mm x 12pcs. + 11.8*33.85mm x 4pcs.

(R): 14*14*2mm x 16pcs. + 15*15*2.5mm x 8pcs. + 11.8*33.85mm x 4pcs.

CutterHead Washer:

0.1 to 0.5, 1, 2, 5, 10, 20mm

Cutterhead Travel System

Mechanical Actuators

Feed Speed

90M/min.

Processing Speed 24M/min. -

Base on 2M Boards

Clamping: Clamps on Top and Side

Controls

Manual or Automatic

Air Service Unit

Norgren

Air Consumption

12CFM

Dust Collection Hood

6" x1

Max. RPM of Cutterhead Spindles

7000RPM

Table to floor height

950mm

Structure

1 With Motor In Feed Roller Table: 3300mm(L) & Foot Stand (3sets/unit) 2. Without Motor Out Feed Table: 2200mm(L) & Foot Stand (2sets/unit) 3. With CE Standard
