Product Details

With digital readout

Saw Head Tilting from 0 to 45 Degrees

Max. Working Size

300mm(W) x 250mm(H)

Conveyor belt size

285mm x 5470mm

Saw wheel dimension

Φ28" x 1"(Thickness)

Saw blade size

180" x 1" (4570mm x 27mm)

Saw wheel motor

30HP

Dust hood diameter

ø4"

Elevation Motor

1/4HP

Feed speed

0-13M/min

Hydraulic System

Motor 3HP / In-feed Speed VMP250 / Out-feed Speed VMP160

Structure

1 Band Wheel Tracking by Liner Guide Way

2. Pneumatic Pressure Roller System for Accurate Cutting

3. Hold Down Roller by Air Cylinder

4. With Return Conveyor: Belt size 185mm x 5470mm

5. With Mist Coolant System for Saw Blade

6. With Air Compensation System

7. With 30HP Inverter
