詳細規格

Max. Log Length

9000mm

Saw Blade size (L x W)

8,185 mm x 1.0T x 5"

Bed Length

11900mm

Saw Wheel Diameter

Φ 1,033 mm

Saw Wheel Thickness

5"

Saw Blade Elevation Distance

50-1300mm

Log Turner

3

Log Clamp (2 pcs. for 1 set)

4

Log Posts

4

Log Transporters

4

Dust Hood Diameter

Φ 200mm x1

Infeed Speed

5-15M/min

Saw Blade Tension System

Hydraulic System

Main Motor

50HP (37kw)

Hydraulic motor

15HP (11KW)

Elevation motor

5HP 3KW with reducer motor

Laser Light

Green 12M

Saw Wheel Speed

750RPM

N.W.

10,000 (±500) kgs
