1.With digital readout
2.Max. workpiece size: 100mm(W) x 100mm(H)
3.Distance from blade to conveyor Table: 3-100mm
4.Conveyor belt size: 95mm x 5470mm
5.Saw wheel dimension: Φ32" x 1"(Thickness)
6.Max. infeed speed: 40M/min
7.Saw blade size: 168" x 1"
8.Saw wheel motor: 20HP
9.Controlling blade tension: Pneumatic-Hydraulic system
10.Conveyor Motor: Motor 2HP with inverter
11.Gear box motor: 1/4HP
12.Dust hood diameter: ψ4" x4
13.Net weight: 950kgs
14.Packing dimensions with pallet:
    - Frame   : 2280 x 1240 x 1230mm / 1,048kg (1set)

    - Conveyor: 2890 x 450 x 690mm / 237kgs (1set)

    - Conveyor: 2890 x 940 x 670mm / 474 KG (2set)
15.Min. working length request: 150mm
16.Pneumatic pressure roller system for accurate cutting
17.Front pressure roller with air cylinder and bumper
18.Tolorance: (5-20M/min. ±0.1ｍｍ) (20-35M/min. ±0.3mm)
19.Mist coolant system
20.With saw dust scraper and Wool Pad
21._______Volt, _______Hertz
