Product Details

With digital readout

Yes

Max. workpiece size

300mm(W) x 250mm(H)

Distance from Upper Blade to Conveyor Table

15-170mm

Distance from Lower Blade to Conveyor Table

7-125mm

Conveyor Belt Size

285mm x 5470mm

Saw Wheel Dimension

Φ28" x 2" (Thickness)

Saw Blade Size

168" x 2"

Max Feed Speed

45 M/min (Depends on workpiece dimension)

Saw Wheel Motor

30HP x 2 (With Inverter)

Controlling Blade Tension

Pneumatic-Hydraulic System

Conveyor Motor

2HP (With Inverter)

Saw-head Up & Down Motor

1/4HP x 2

Dust Hood Diameter

Φ4" x 3

Min. Working Length

500mm (Shorter length upon request)

Tolerance

5-25 M/min ±0.1mm / 25-45 M/min ±0.3mm

Saw Kerf

1.35mm

Dust Collection Requirement

2000 CFM

Net Weight

1580 kgs

Packing Dimensions

Frame: 2190 x 1140 x 2130mm / 1414kgs

Conveyor: 2870 x 630 x 750mm / 207kgs

Additional Features

Pneumatic pressure roller system

Front & Back Bumper

Front pressure roller with air cylinder & shock absorber

Mist coolant system x 2

Saw dust scraper & wool pad

Pressure roller height adjustment system
