Product Details

With digital readout

Max. workpiece size

1300mm(W) x 250mm(H)

Distance from Blade to Conveyor Table

4-250mm

Conveyor belt size

1275mm x 10300mm

Saw wheel dimension

Φ42" x 4"(Thickness)

Saw blade size

8072mm(L) x 4"(W) x 1.0mm(Thickness)

Saw wheel motor

40HP

Conveyor System

-Hydraulic 5 HP motor (Optional:Hydraulic System w/ 5HP Motor )

Inverter motor

40HP

Min. working length

500mm

Dust hood diameter

4" x1

Elevation Motor

1HP

Feed speed

0-10M/min

Structure

1.    Pneumatic Pressure Roller System

2.    Hold Down Roller by Air Cylinder

3.    With Mist Coolant System for Saw Blade

4.    With Air/Hydraulic Compensation System

5.    With Air/Hydraulic Compensation System
